SS 316 Angle Needle Valve, 1/2 Inch, 10000 PSI, MNPT * FNPT

Key Specifications / Features

The SS 316 Angle Needle Valve, manufactured in China, features a durable stainless steel body designed for high-pressure applications. With a 1/2-inch (DN15) size and a pressure rating of 10,000 PSI, this valve ensures reliable performance under demanding conditions. It is equipped with male x female NPT end connections, offering secure and leak-proof installation.

The angle-type thread needle valve is known for its long service life, high-temperature resistance, and vertical movement of the valve tip, which eliminates rotation. This results in enhanced durability and a lightweight, ergonomic design. Made from high-temperature and high-pressure stainless steel, it is a critical component in instrument measurement pipeline systems. The valve offers easy installation and disassembly, tight connections, fire prevention, explosion-proof properties, high-pressure resistance, and excellent sealing performance. Commonly used in power plants, refineries, chemical plants, and instrument measurement pipelines, it acts as a flow switch for high-pressure gas and liquid. The product is reliable, and customized non-standard valves can be designed and produced according to user specifications.

Technical Specifications

» Product Model: J14/24Y
» Type: Angle
» Usage: Cut-off
» Nominal Diameter: DN6-DN100 mm, 1/8-4 Inch
» Nominal Pressure: 1.0 - 42.0 MPa, PN10-PN420
» Main Materials: SS 304, SS 316
» Connection Method: Male x Female Threaded
» Working Temperature: -54°C to 316°C (-65°F to 600°F)

Product Performance

» Low torque design for lightweight and easy operation
» Traceable raw materials for all main components
» PTFE or flexible graphite sealing pressure device, ensuring no leakage during valve stem operation
» Compact structure with an attractive appearance, flexible use, tight connection, and excellent sealing performance
» Easy installation and disassembly, secure connections, and advantageous for fire prevention, explosion-proof, high-pressure resistance, and good sealing performance
