SUS 304 Needle Valve, 6000 PSI, DN10, 3/8 IN, Soft Seal, SW

Key Specifications / Features

The SUS 304 Needle Valve is a high-pressure valve designed for precise flow control in demanding applications. Made from durable stainless steel, it features a DN10 (3/8 inch) size and is rated for a pressure of 5000 PSI. Equipped with socket welded ends, this valve ensures secure connections and reliable performance in high-pressure systems.

The stainless steel socket-welded high-pressure needle valve is a robust, high-performance valve designed for demanding applications. It is forged under high pressure as a single unit, with the valve body undergoing strengthening treatment to enhance durability. The valve is tested to withstand up to 70MPa, with a pressure range of 1.6-200.0MPa and a temperature range of -54°C to 570°C.
The valve disc is welded with a hard alloy, significantly improving its corrosion resistance and impact strength. The sealing element is sourced from MTU (USA), ensuring excellent resistance to high temperature, high pressure, and corrosive environments. The manufacturing process is carefully controlled to ensure precise fabrication, resulting in reliable product quality.

Technical Specifications

» Usage: Cut-off function
» Nominal Diameter: DN6-DN80, 1/8-3 Inch
» Pressure Environment: High Pressure
» Main Material: SS 304, SS 316, SUS 304
» Type (Channel Position): Through
» Sealing Form: Soft seal

Product Features

» Excellent Sealing and Long Service Life: The high-sealing socket-welded high-pressure needle valve ensures tight sealing performance and a long service life. In the event of sealing surface wear, only the vulnerable components need replacement,     extending the valve's operational lifespan.
» Installation and Flow Direction: When installing, ensure the flow direction of the medium aligns with the direction indicated by the arrow on the valve body.
» Advantages: The valve offers easy installation and disassembly, secure connections, and enhanced safety features, including fire prevention, explosion resistance, and high-pressure tolerance. Its excellent sealing performance ensures reliable               operation in critical environments.
» Multifunctional Use: This needle valve is ideal for use in power plants, refineries, chemical plants, and instrument measurement pipelines, where precision and high-performance sealing are essential.
