ASTM A105N Globe Valves, API 602, 2 IN, 600 LB, Bellows Seal

Key Specifications / Features

The ASTM A105N Globe Valves Supplier offers high-quality bellows sealed globe valves designed to meet API 602 standards. These 2-inch (DN50) forged carbon steel valves feature a bellows seal, ensuring leak-tight performance and protecting against fugitive emissions. Rated at Class 300 LB and PN50, they provide reliable flow control in various industrial applications. The valves come with raised face (RF) flanged ends for easy installation and manual operation for precise control.

Forged Steel Globe Valves are designed and manufactured in strict accordance with international standards such as API 602, ASME B16.34, and DIN 3202. They feature a compact yet exceptionally robust construction, making them ideal for high-pressure, high-temperature applications. An optional solid CoCr alloy wedge ensures low friction and extended service life. The packing rings are precompressed to 4000 psi, providing a reliable and high-integrity seal. In welded bonnet configurations, the bonnet is threaded and torqued to a precise value, with the body-bonnet joint strength-welded to deliver dual protection against leakage. The fully guided wedge design minimizes wear on seating surfaces. Optional features include double packing, leak-off connection, live-loading, and a packing blowout function for convenient removal and replacement of worn packing.

Technical Specification

» Size Range: 1/2-2 Inch (Forged items)
» Design Pressure: Class 150 - 600 LB (PN10-PN100)
» Materials: Carbon Steel, Alloy Steel, Stainless Steel, Duplex Steel, and other custom alloys
» Trim Materials: 13% Cr, ASTM A182 F11, F22, SS 304, SS 304L, SS 316, SS 316L, and other special alloys
» End Connections: SW, FNPT, BW, RF, Grooved
» Design & Manufacture Standards: ASME B16.34, API 602
» Face-to-Face (End-to-End): ANSI B16.10
» Flanged Connections: ANSI B16.5
» Testing & Inspection: API 598, API 6D
» Butt Weld Ends: ANSI B16.5
» Socket Weld Ends: ASME B16.11

Product Features

» After fine processing, forged steel materials have good corrosion resistance and are suitable for various corrosive media, extending the service life of valves;
» Forged steel globe valves are usually designed to be more compact, with a smaller volume and less space occupation, making them easy to install and use, especially suitable for working conditions with limited space.
