ASTM A182 F53 Ball Valve, ASME B16.34, SN20, PN260, FNPT

Key Specifications / Features

The ASTM A182 F53 Ball Valve Plant produces high-quality ball valves in accordance with ASME B16.34 standards. These valves feature a 3-piece body design made from forged duplex stainless steel, ensuring excellent strength and corrosion resistance. With a size of 1/2 inch (DN15), a pressure rating of Class 150 LB (PN20), and FNPT (Female National Pipe Thread) threaded ends, they are designed for reliable performance in a variety of applications. The threaded ends provide easy installation and maintenance.

Forged Steel Ball Valves are available in two primary body types: Two-Piece Split Body and Three-Piece Bolted Body. The forging material ensures sufficient rigidity and strength under the maximum rated operating pressure, eliminating the inherent flaws associated with cast materials. The valves feature adequate wall thickness and the use of high-strength tie bolts, which facilitate easy maintenance and are capable of withstanding pipeline stress. The internal components of the valve are meticulously designed and selected to ensure reliability under various working conditions.

Technical Specification

» Size Range: 1/2-2 Inch (DN15-DN50) (for Forged Items)
» Design Pressure: Class 150-1500 LB (PN10-PN250)
» Materials: Carbon Steel, Alloy Steel, Stainless Steel, Duplex Steel, etc
» Trim Materials: 13%Cr, ASTM A182 F11, F22, SS 304, SS 304L, SS 316, SS 316L
» Seat Materials: PTFE, RPTFE, PEEK
» Ends Connections: SW, FNPT, BW
» Design and Manufacture: ASME B16.34
» Face to Face (End to End): ANSI B16.10
» Flanged Connection: ANSI B16.5
» Test and Inspection: API 598, API 6D
» Butt Welded Ends: ANSI B16.5
» Threaded Ends: ASME B1.20.1
» Socket-Weld Ends: ASME B16.11

Product Features

» Body Types: Available in One Piece Uni-body, Two Piece Split Body, and Three Piece Bolted Body configurations.
» Standards Compliance: Designed and manufactured in accordance with the most up-to-date international standards, including API 6D, ASME B16.34, BS 5351, or their equivalents.
» Safety Features:
   Fire Safe: Designed to maintain integrity and prevent leakage in the event of a fire.
   Anti-static: Incorporates features to prevent the buildup of static electricity, enhancing safety in flammable environments.
   Blow-out Proof: Ensures that the stem remains securely attached to the valve body even under extreme pressure conditions, preventing blow-out incidents.
