ASTM A351 CF8M Wedge Gate Valves, DIN 3352, 28 IN, CL300, RF

Key Specifications / Features

The ASTM A351 CF8M Wedge Gate Valves Supplier offers high-quality gate valves designed according to DIN 3352 standards. These valves feature a cast stainless steel body made from CF8M material, ensuring excellent corrosion resistance and durability. With a large size of DN400 (16 inches) and a pressure rating of PN16 (Class 150 LB), they are suitable for a variety of industrial applications. The valves have RF (Raised Face) flanged ends for secure and reliable connections. They are operated by a bevel gear mechanism.

Wedge Gate Valves are engineered to meet stringent environmental standards, designed to ensure leakage of volatile organic compounds (VOCs) remains below 100 ppm (parts per million). Comprehensive laboratory testing, including static and cycle testing, has established critical design parameters to ensure low-emission sealing in both the stem packing and bonnet gasket areas. A robust in-house testing procedure verifies that each valve meets this low-emission benchmark prior to shipment, ensuring consistent quality and performance in the field.

Technical Specifications

» Product Type: Wedge Gate Valve
» Nominal Diameter: DN50 to DN1000
» Design Pressure: PN6 to PN25
» Body / Bonnet / Wedge Materials: Carbon Steel (EN 1.0619), Stainless Steel (EN 1.4308, EN 1.4408), Alloy Steel (EN 1.7335/ASTM A217 WC6)
» Stem Material: X20Cr13 (EN 1.4021), Stainless Steel (EN 1.4308, EN 1.4408)
» Seat Material: 13Cr, 18Cr, Stellite
» End Connections: Raised Face (RF) Flange, Groove Flange, Butt Weld (BW)
» Operation Modes: Handwheel, Bevel Gear, Electric Actuator, Pneumatic Actuator
» Structural Design: BB-BG-OS&Y (Bolted Bonnet, Outside Stem & Yoke)
» Design Standard: DIN 3352
» Face-to-Face Dimension: EN 558-1, Series 15 (DIN 3202 F5)
» Flanged Ends: DIN 2543–2547, EN 1092-1, GOST 12815 / 12819
» Butt Welded Ends: EN 12627
» Testing & Inspection: DIN 3230

Product Features

» Anti-Friction Ball Thrust Bearing: Ensures smooth operation by reducing friction between moving parts
» Grub Screw: Secures the yoke nut firmly in the bonnet
» Grease Nipple: Facilitates easy lubrication of moving components
» OS&Y Construction: External stem and yoke design for reliable stem positioning
» Metal-Seated Options: Available trim numbers include #1, #5, #8, #10, and more
» Locking device for secure positioning
» Stem extension for remote access
» Direct actuator mounting to ISO 5211 standard
» Full Port Design: Ensures minimal flow restriction for efficient throughput
