Stainless Steel Ball Valve 22.225mm AISI304 316 420 Stainless Steel Bearing Balls for Agricultural Machinery Bearing Grinding
- Type:
- Floating Ball Valve
- Application:
- Water Industrial Usage
- Features:
- AISI430
- Structure:
- Floating Ball Valve
- Standard:
- ISO
- Temperature:
- Ultralow Temperature
- HS Code:
- 84829100
Applications:
For 300 series stanless steel balls, they are used in Trigger sprayers,Bearings,Dispenser valves,Body jewelry lotion pumps, and so on.
For 400 series stainless steel balls, they are most used in Bearing applications,Valve, Locking mechanisms,Fasteners,and so on.
Chermical Composition:
| AISI Number |
C% | Si% | Mn% | Cr% | Ni% | Mo% | P% | S% | property |
| AISI 304 | 0.07 MAX |
1.00 MAX |
2.00 MAX |
17.0~ 19.0 |
8.0~ 10.5 |
0.045 MAX |
0.03 MAX |
Slightly magnetic,flat surface HRC 25min. |
|
| AISI 316 | 0.07 MAX |
1.00 MAX |
2.00 MAX |
16.5~ 18.5 |
10.5~ 13.5 |
2.00~ 2.50 |
0.045 MAX |
0.03 MAX |
Better corrosion resistance than SS304 specially against Sulfuric acid and ink/bleach/nitric |
| AISI 420 | 0.07~ 0.25 |
1.00 MAX |
1.00 MAX |
12.0~ 14.0 |
0.045 MAX |
0.03 MAX |
Magnetic,martensite steel. flat surface HRC 50min, better corrosion resistant |
||
| AISI 430 | 0.08 MAX |
1.00 MAX |
1.00 MAX |
15.5~ 17.5 |
0.045 MAX |
0.03 MAX |
Ferritic stainless steel,better corrosion resistant than 3series at higher temperature | ||
| AISI 440 | 0.95~ 1.20 |
1.00 MAX |
1.00 MAX |
16.0~ 18.0 |
0.045 MAX |
0.02 MAX |
Martensite,fair corrosion to water,alcohol,oil and food product. |
Hardness: HRC25-39 ( without demagnetization treatment)
special hardness can be made according to the customer's requirement.
Ball Surface:Bright, Zero Defect
Certification:ISO 9001:2015
Safe:RoHS SGS
